PEM 3.1 SX

PEM 3.1 SX is a precision electrolytic machining (PEM) system produced by PEM Technologies, a company specializing in the development and manufacture of advanced electrochemical machining systems. The PEM 3.1 SX is a high-precision, multi-axis machining system that is capable of machining a wide range of materials, including hard and brittle materials such as ceramics, glass, and tungsten carbide.

Overall, the PEM 3.1 SX is a highly advanced and versatile PEM system that is designed for precision machining of a wide range of materials. Its advanced features and user-friendly interface make it an ideal option for applications that require high-precision machining and complex geometries.

TECHNICAL DATA

• Machining accuracy:
  The PEM 3.1 SX is capable of achieving sub-micron accuracy, with a positioning accuracy of ±0.001 mm and a surface finish of Ra 0.1 μm.
• Workpiece dimensions:
  The system can accommodate workpieces with dimensions up to 300 mm x 300 mm x 200 mm.
• Axis configuration:The PEM 3.1 SX is a 4-axis system, with X, Y, Z, and C axes.
• Workpiece weight:
  The maximum workpiece weight that the system can handle is 50 kg.
• Electrolyte control:
  The system features precise control of the electrolyte flow rate, temperature, and concentration, which allows for consistent and high-quality machining results.
• Adaptive machining:
  The system is equipped with adaptive machining technology, which allows it to adjust machining parameters in real-time based on changes in the workpiece material or thickness.
• Cooling system:
  The system is equipped with an efficient cooling system that allows for continuous operation without overheating.
• Materials:
  The PEM 3.1 SX can machine a wide range of materials, including hard and brittle materials such as ceramics, glass, and tungsten carbide, as well as metals such as titanium, stainless steel, and aluminum.
